AIR COOLED AFTER COOLER
cool air at the source.
An After Cooler is the first piece of compressed-air treatment equipment installed right after the compressor discharge — and it does the heavy lifting that every downstream filter and dryer counts on. Compressed air leaves a screw or reciprocating compressor at 80°C to 120°C, saturated with hot moisture. If that hot, wet air enters your line untreated, it overloads your dryer, floods your filters, corrodes your pipework and rains condensate at every drain point.
Our Air-Cooled After Coolers use a high-efficiency finned-tube heat exchanger with axial cooling fans to drop the air temperature down to within 5–10°C above ambient — knocking out up to 70% of the moisture as bulk condensate before the air ever reaches your dryer. No cooling water lines, no plumbing, no maintenance overhead. Just plug-and-play heat rejection.
WATER COOLED AFTER COOLER
for high-flow plants.
When your plant pushes high CFM, sits in a hot ambient environment, or already has a cooling-water loop, the Water-Cooled After Cooler is the right choice. Built around a robust shell-and-tube heat exchanger with compressed air flowing through the tube side and cooling water on the shell side, it achieves a much closer approach temperature of just 3–5°C above the cooling-water temperature — meaning drier, cooler discharge air, every cycle.
Because cooling water carries heat away far more efficiently than air, water-cooled units are compact for their capacity, virtually silent, and remove up to 80% of moisture as bulk condensate right at the source. They pair seamlessly with cooling towers and chiller loops you may already have installed for other process equipment.
FIRST STAGE OF CLEAN AIR
protects everything downstream.
Protects Your Dryer
A dryer that receives 90°C air uses ~3× more energy and may not achieve its rated dew point. An after cooler cuts that load to a tiny fraction.
Removes Bulk Moisture
Up to 80% of the water vapour in compressed air drops out as liquid condensate at the after-cooler outlet — never reaching your downstream filters.
Saves Energy
Cooler air is denser air. Less work for your downstream equipment — lower kW draw on dryers, longer life for desiccant beds, less wear on auto-drain valves.
Prevents Pipe Damage
Hot wet air corrodes carbon-steel pipework from inside. A properly sized after cooler keeps your distribution lines cool, dry and rust-free.
Improves Tool Life
Pneumatic tools love cool, dry, oil-mist-free air. An after cooler is the first step toward extending tool MTBF and reducing seal failures.
Fast Payback
Most after-cooler installations pay back inside 12–18 months through reduced dryer load, fewer breakdowns and longer equipment life.
CHOOSE THE RIGHT VARIANT
NOT SURE WHICH AFTER COOLER FITS?
Share your compressor capacity, ambient temperature and cooling-water availability — we'll size the right unit and quote within 24 hours.
